AMS 5504 Stainless Steel Flat Bar UNS S41000 Sheet Steel

Name: AMS 5504 Stainless Steel Flat Bar UNS S41000 Sheet Steel
Brand: PANGANGGROUP,TISCO,ANSTEEL,BAOSTEEL
Price: 1 USD

AMS 5504 Stainless Steel Flat Bar UNS S41000 Sheet Steel Manufactures

Brand Name : PANGANGGROUP,TISCO,ANSTEEL,BAOSTEEL

Model Number : AMS 5504, UNS S41000

Certification : SGS, TUV, BV, ISO, MTC

Place of Origin : China

MOQ : 1000kg

Price : Negotiations

Payment Terms : T/T

Supply Ability : 45000KGS/Month

Delivery Time : Ex-stock for delivery: 3-7 days Production lead time: 30-60 days

Packaging Details : Wooden Pallet BOX;Standard Seaworthy Package;based on the customer's special requirement

Characteristic : Corrosion and Heat-Resistant

Heat treatment condition : +N, +NT, etc.

Processing methods : Milled, Cold working. etc

Available Shapes : Sheet, Strip,and Plate...

Surface : peeled + polishing, etc.

Application : Turbine blades, bolts, hydraulic valves

Material Category : Martensitic stainless steel

Contact Now

AMS 5504 Stainless Steel Flat Bar UNS S41000 Sheet Steel

Describe

AMS 5504 stainless steel is a general-purpose martensitic stainless steel containing 11.5% chromium with good corrosion resistance. However, through a series of processes such as quenching, tempering, and polishing, the corrosion resistance of AMS 5504 steel can be further enhanced. Quenching and tempering can harden AMS 5504 steel. They are typically used in applications involving mild corrosion, heat resistance and high strength.

Martensitic stainless steels are manufactured using techniques that require a final heat treatment. These grades have poor corrosion resistance compared to austenitic grades. Their operating temperature is often affected by loss of strength at elevated temperatures due to overtempering and loss of ductility at sub-zero temperatures.

Size Range

Round bar / Wire rod (Diameter):	3.5mm to 900mm
Square bar / Flat bar:	3.0mm to 1000mm
Forging piece:	Stepped shafts with flanks / discs /tubes /slugs /donuts /cubes /other different shapes based on OEM.
Heavy/middle plate via hot rolled:	T6 - 350mm X W10 - 1500mm X L1000-12000mm
Sheet steel via cold rolled:	T0.5 - 5mm X W6 - 1000mm X L1000 - 1100mm
Steel strip via cold rolled:	T0.1 - 4.0mm X W5 - 190mm X L (or in coil form)
Length	Fixed length or random length or based on the customer's special requirement.

Chemical Composition and standard

Grade	AMS 5504
standard	SAE AMS 5504M-2012
Chemical Composition (weight%)	C(％): ≤0.15 Cu(％): ≤0.50 Si(％): ≤1.0 Al(％): ≤0.05 Mn(％): ≤1.0 Sn(%): ≤0.05 P(％)≤: 0.04 N(%): ≤0.08 S(％)≤: 0.03 Cr(％): 11.5~13.5 Ni(％): ≤0.75 Mo(％): ≤0.50

AMS 5504 Stainless Steel Flat Bar UNS S41000 Sheet Steel

Mechanical Properties

AMS 5504 Stainless Steel Mechanical Properties

Tensile strength,Rm/MPa:	448~655
Yield strength,Rp/MPa:	≥207
Elongation/%:	12~15
Reduction of area, ψ/%:	--
Impact, KV /J:	--
Annealed hardness HB:	--

Contact us

We look forward to cooperating with you, please let us provide you with better service, contact us

sales@ss-bars.com

AMS 5504 Stainless Steel Flat Bar UNS S41000 Sheet Steel

Product Tags:

AMS 5504 Stainless Steel Flat Bar

UNS S41000 Sheet Steel

AMS 5504 Stainless Steel Flat Bar UNS S41000 Sheet Steel Images
